WEICHAI Engine【WP2.3 series marine diesel engine (40-95kW)
- Type:Weichai
- CAS No:
- Qty in 20' FCL:
- Min. Order:
- Packaging:
-
Product Parameter
Engine Type 4-stroke, Water-cooled, Inline, Turbocharged Intercooler Cylinder Count 4 Bore/Stroke 89×92(mm) Displacement 2.3L Starting Method Electric Start Oil Consumption ≤0.1g/kW·h Noise Level ≤96dB(A) Idle Speed 750r/min Crankshaft Rotation Direction
(when facing flywheel end)Counterclockwise Net Weight 310kg Dimensions (L×W×H) 730×688×822(mm) Product Model
Series Model Intake Method Rated Power kW/Ps Rated Speed r/min Fuel Supply Method Emission Level Power Level WP2.3N* WP2.3NC54-18E220 Turbocharged Intercooler 40/54 1800 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NC68-18E220 Turbocharged Intercooler 50/68 1800 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NC82-18E220 Turbocharged Intercooler 60/82 1800 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NC102-21E220 Turbocharged Intercooler 75/102 2100 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NY102-21E220 Turbocharged Intercooler 75/102 2100 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NC110-25E220 Turbocharged Intercooler 81/110 2500 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NY110-25E220 Turbocharged Intercooler 81/110 2500 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NC130-32E220 Turbocharged Intercooler 95/130 3200 Electronically Controlled Common Rail IMO II / China Stage II P1 WP2.3NY130-32E220 Turbocharged Intercooler 95/130 3200 Electronically Controlled Common Rail IMO II / China Stage II P1
-
Product Description
The WP2.3 Series Marine Diesel Engine (40-95kW) is a high-performance, durable power solution specifically designed for various types of vessels. Engineered for efficiency and reliability, this engine series provides exceptional power output, fuel economy, and extended service life, making it ideal for maritime operations.
Key Technical Parameters
1. Torque Reserve: 34% — Provides strong low-speed torque, ensuring excellent acceleration and reliable performance even in challenging maritime conditions.
2. Minimum Fuel Consumption: 195g/kW·h — Optimized fuel efficiency reduces operational costs, enhances environmental sustainability, and ensures longer operational range with less fuel consumption.
2. Overhaul Interval: 12,000 hours — A long overhaul interval significantly reduces maintenance requirements, lowering long-term operational costs and enhancing engine reliability over time.
Product Features
1. Efficient Fuel Use
The WP2.3 Series Diesel Engine is engineered to deliver high fuel efficiency with low emissions, helping vessel operators save on fuel costs and meet modern environmental standards.
2. Robust Power Output
Even at low speeds and under heavy load, the engine provides steady, reliable power to ensure optimal performance across a variety of maritime tasks.
3. Extended Service Life
With a long overhaul interval of up to 12,000 hours, the WP2.3 engine offers improved longevity, reducing the need for frequent maintenance and parts replacement.
4. Low Maintenance Requirements
Designed for durability and easy maintenance, the WP2.3 engine minimizes downtime and maintenance efforts, reducing the overall operating cost for ship owners.
5. Versatile Application
Suitable for a wide range of mid-to-small-sized vessels, including fishing boats, commercial ships, and patrol boats, the WP2.3 engine excels in diverse marine environments.
-
