Detailed Parameters of 16A Marine Gearbox
The 16A marine gearbox has the functions of slowing down, pouring, shun clutch and bearing propeller thrust. The gearbox is a vertical heterogeneous first-stage transmission structure, with small size, light weight and other characteristics.
16A Marine gearboxes are suitable for small fishing vessels, transport vessels, traffic boats, passenger ships and other vessels.
|
The input speed |
1000-2000r/min |
||
|
Reduction ratio |
2.07、2.48、2.95、3.35、3.83 |
Transmission capacity |
0.012kw/r/min |
|
Manipulating type |
manual |
||
|
The rated thrust |
3.5KN |
||
|
Center distance |
135mm |
||
|
Length x width x height |
422×325×563mm |
||
|
The net weight |
84kg |
||
|
Join the flywheel |
2105C 395、SAE11.5、10 |
||
|
Join the trim |
2105C 395、SAE3、4 |
||
Besqo Marine offers a wide range of Host Device. For more information, leave message or send an email to sales@besqo.com.
