Weichai
WEICHAI Engine【WP2.3N Marine Diesel Engine Series(40-95kW)】
- Type:Weichai
- CAS No:
- Qty in 20' FCL:
- Min. Order:
- Packaging:
Save Big Now, Discount Expires Soon.
-
Parameters Table
Type Four-stroke, water cooled, in-line, turbocharged and intercooledNumber of cylinders 4 Cylinder Bore/stroke 89×92(mm) Displacement 2.3L Oil consumption rate ≤0.1g/kW·h Noise ≤96dB（A） Minimum fuel consumption rate 190g/kW·h Idle speed 750r/min Rotation direction of crankshaft
(facing the flywheel end)Counter-clockwise Net weight 310kg Dimensions Length × Width × Height 730×688×822（mm）
Model Portfolio Table
Series Model Air intake mode Rated power kW/Ps Speed r/minn Fuel feeding mode Emission level Power classification WP2.3N* WP2.3NC54-18E220 Turbocharged and intercooled 40/54 1800 HPCR - P1 WP2.3NC68-18E220 Turbocharged and intercooled 50/68 1800 HPCR - P1 WP2.3NC82-18E220 Turbocharged and intercooled 60/82 1800 HPCR - P1 WP2.3NC102-21E220 Turbocharged and intercooled 75/102 2100 HPCR - P1 WP2.3NC110-25E220 Turbocharged and intercooled 81/110 2500 HPCR - P1 WP2.3NC130-32E220 Turbocharged and intercooled 95/130 3200 HPCR - P3 Remark: The delivery date of products marked with * shall be subject to the reply of the manufacturer. Product parameters and model portfolio are for reference only. Please contact relevant personnel for official information on delivery time and fishing boat model portfolio.
-
Product Profile
Weichai brand new N series platform products, the body, cylinder head, piston, bearing shell and other structural parts of a new design;Adopt high-quality Weichai system suppliers and develop in accordance with the high reliability requirements of large-displacement engines;Dust-free, constant temperature assembly workshop, high precision test bench.
High torque in medium and low speed range, continuous output and strong power.Precise control by electronic control unit, high injection pressure and superior acceleration performance.50% rated speed can reach 134% rated torque .Using electronic control high pressure common rail technology, accurate control of fuel injection, economic operation area is wider.Minimum fuel consumption rate 195g/kW•h.
Oil replacement cycle ≥500h .Electronic control multiple injection, greatly reduce vibration and noise, idle noise 74dB (A).NVH optimization matching of the whole machine, gear chamber cover, cylinder cover, closed flywheel housing noise reduction design, reduce noise leakage.Adopt body stiffening plate, piston pin offset structure, the vibration of the whole machine is better than that of competing products.Emissions meet the requirements of IMOⅡ.
Weichai intelligent cloud platform, big data processing, remote diagnosis.Intelligent terminal, maintenance reminder.Horizontal filter arrangement, reduce the height of the machine, compact structure.Optional Internet intelligent instrument, installed sea water pump, damping pad and other configurations, to meet the needs of different customers
