AD501 Address Code P rogrammer Parameters
Product Name: AD501 Address Code Programmer
Product Features
Small size, easy to carry
With its own DB501 base and DB502 base, the bus device can be swiveled directly to input address, easy to use.
With low battery voltage indicator
-
Operation Voltage
DC24V or DC18V
Quiescent Current
≤1.7mA/DC24V；≤1.7mA/DC18V
Working current
≤2.7mA/DC24V；≤2.2mA/DC18V
Operating temperature
-10℃～+50℃
Relative humidity
≤95%
Dimensions
107mm×40mm×180mm（L×W×H）
Weight
About 150g
Color
White
