CL-4 High Bearing Capacity Marine Rubber Bag Parameters
The CL-4 High Bearing Capacity Marine Rubber Bag is a specially designed rubber product, specially manufactured for the high bearing requirements of the Marine industry. This rubber bag uses high-strength materials and special production processes to withstand greater pressure and weight.
CL-4 High Bearing Capacity Marine Rubber Bags also have good elasticity and flexibility, and can be customized according to the shape and size of the cargo to maximize loading efficiency and space utilization. At the same time, it also has excellent sealing performance, which can effectively prevent cargo leakage and moisture.
-
Bearing Capacity of CL-4 High Bearing Capacity Marine Rubber Bag Unit Length
tube
diameterWorking
pressureWorking
heightGuaranteed Value of Bearing
Capacity per Unit LengthKN/m
t/m
Ib/ft
D=12M
(D=3.94ft)0.11MPa
(15.95psi)0.7m(2.296ft)
86.43
8.81
5921
0.6m(1.968ft)
103.69
10.57
7104
0.5m(1.640ft)
121.06
12.34
8294
0.4m(1.312ft)
138.32
14.1
9477
0.3m(0.984ft)
155.59
15.86
10660
0.2m(0.656ft)
172.85
17.62
11843
D=1.5M
(D=4.92ft)0.09MPa
(13.05psi)0.9m(2.952ft)
84.86
8.65
5814
0.8m(2.624ft)
98.98
10.09
6782
0.7m(2.296ft)
113.21
11.54
7756
0.6m(1.968ft)
127.33
12.98
8724
0.5m(1.640ft)
141.46
14.42
9692
0.4m(1.312ft)
155.59
15.86
10660
0.3m(0.984ft)
169.71
17.3
11628
0.2m(0.656ft)
183.94
18.75
12602
D=1.8M
(D=5.90ft)0.08MPa
(11.60psi)1.1m(3.608ft)
88.09
8.89
6036
1.0m(3.280ft)
100.65
10.26
6896
0.9m(2.952ft)
113.21
11.54
7756
0.8m(2.624ft)
125.76
12.82
8617
0.7m(2.296ft)
138.32
14.1
9477
0.6m(1.968ft)
150.88
15.38
10337
0.5m(1.640ft)
163.53
16.67
11204
0.4m(1.312ft)
175.6
17.9
12031
0.3m(0.984ft)
186.68
19.03
12791
0.2m(0.656ft)
201.11
20.5
13779
