Sundry hanging【HH-YD21】 Parameters

This landing device is mainly used for hoisting rescue boat/raft and special equipment for hoisting materials. The device has the functions of electric (manual) lifting, gravity lowering and hydraulic rotary (pump station and accumulator can supply oil separately).

Control methods: the two methods are side-engine control and in-boat remote control. There are two types of device to meet the ship port and starboard arrangement requirements. When the ship heeling 200 or 100, the device can work normally.

This device meets the relevant requirements of msc.47 (66)1974 amendments to the international convention on the safety of life at sea and msc.216 (82) and international maritime organization msc.48 (66)& msc.218 (82) international life-saving equipment.

Main technical parameters of lifesaving part:

Workload: 21KN
Lifting load: 14KN
Lifting speed: 18m/min
Lowering speed: 4050m/min
Turning radius: 5m(can be designed as required)
Wire rope diameter: 16mm
Drum rope capacity: 25mm
Lifting main technical parameters:
Workload: 15KN
Lifting load: 15KN
Lifting speed: 12m/min
Turning radius: 6.5m (can be designed as required)
Wire rope diameter: 13mm

Drum rope capacity: 25m

USES:	Marine salvage
Material:	assembly
Type:	Hh-yd21 and miscellaneous crane crane
Processing and customization:	Yes
Sample or stock:	The spot

Besqo Marine offers a wide range of Deck Machinery. For more information, leave message or send an email to sales@besqo.com.
