Hall Anchor A B C Type Parameters
This Hall Anchor A B C Type is made of high quality marine cast carbon steel ZG200-400C,
The use of advanced processes and treatment methods,
Products have reached the China Classification Society certification standards.
According to customer requirements to provide CCS, NK, DNV, LR recognition certificate, For a certificate, please call the consultation to include the certificate price.
TYPE ABC HALL ANCHOR SIZE LIST
|
Nominal |
SIZE(mm) |
|||||||
|
H |
h |
hl |
L |
LI |
BI |
|||
|
Atype |
Btype |
Ctype |
||||||
|
40 |
SS7 |
557 |
430 |
303 |
67 |
430 |
303 |
198 |
|
60 |
637 |
637 |
492 |
347 |
76 |
492 |
347 |
227 |
|
100 |
760 |
760 |
590 |
410 |
90 |
584 |
410 |
227 |
|
125 |
814 |
814 |
629 |
443 |
97 |
629 |
443 |
290 |
|
150 |
866 |
866 |
665 |
470 |
103 |
760 |
470 |
308 |
|
180 |
919 |
919 |
718 |
300 |
109 |
710 |
S00 |
327 |
|
240 |
1019 |
1019 |
788 |
552 |
120 |
790 |
552 |
361 |
|
300 |
1095 |
1095 |
850 |
595 |
130 |
844 |
595 |
388 |
|
360 |
1160 |
1160 |
898 |
630 |
138 |
898 |
630 |
412 |
|
420 |
1160 |
1160 |
946 |
660 |
145 |
946 |
660 |
434 |
|
480 |
1222 |
1222 |
986 |
690 |
152 |
988 |
690 |
454 |
|
570 |
1355 |
1355 |
1042 |
732 |
161 |
1042 |
732 |
481 |
|
660 |
1356 |
1356 |
1093 |
769 |
169 |
1096 |
769 |
506 |
|
780 |
1506 |
1506 |
1170 |
813 |
178 |
1160 |
813 |
535 |
|
900 |
1580 |
1580 |
1215 |
855 |
188 |
1220 |
855 |
360 |
|
1020 |
1645 |
1645 |
1268 |
855 |
188 |
1220 |
855 |
S60 |
|
1140 |
1705 |
1705 |
1316 |
926 |
203 |
1319 |
926 |
605 |
|
1290 |
1778 |
1778 |
1378 |
891 |
195 |
1268 |
891 |
584 |
|
1440 |
1844 |
1844 |
1448 |
965 |
203 |
1379 |
965 |
630 |
|
1590 |
1906 |
1906 |
1511 |
1035 |
226 |
1475 |
1035 |
677 |
|
1740 |
1966 |
1966 |
1571 |
1068 |
234 |
1517 |
1068 |
698 |
|
1920 |
2031 |
2031 |
1602 |
1104 |
241 |
1568 |
1104 |
722 |
|
2100 |
2093 |
2093 |
1651 |
1120 |
245 |
1560 |
1120 |
732 |
|
2280 |
2150 |
2150 |
1716 |
1165 |
225 |
1657 |
1165 |
763 |
|
2460 |
2207 |
2207 |
1785 |
1194 |
262 |
1700 |
1194 |
784 |
|
2640 |
2259 |
2259 |
1843 |
1222 |
265 |
1730 |
1222 |
796 |
|
2850 |
2318 |
2318 |
1890 |
1253 |
275 |
1787 |
1253 |
822 |
|
3060 |
2374 |
2374 |
1935 |
1283 |
282 |
1832 |
1283 |
841 |
|
3300 |
2432 |
2432 |
1985 |
1317 |
288 |
1880 |
1317 |
862 |
|
3540 |
2490 |
2490 |
2032 |
1349 |
295 |
1926 |
1394 |
883 |
|
3780 |
2547 |
2547 |
2077 |
1376 |
302 |
1965 |
1376 |
902 |
|
4050 |
2610 |
2610 |
2125 |
1406 |
309 |
2008 |
1406 |
924 |
|
4320 |
2695 |
2695 |
2171 |
1435 |
316 |
2051 |
1435 |
943 |
|
4590 |
2712 |
2712 |
2216 |
1465 |
332 |
2093 |
1465 |
962 |
|
4890 |
2769 |
2769 |
2263 |
1498 |
329 |
2135 |
1498 |
954 |
|
5000 |
2800 |
2800 |
2317 |
1510 |
32 |
2156 |
1510 |
992 |
|
5610 |
2899 |
2899 |
2369 |
1569 |
345 |
2234 |
1569 |
1031 |
|
6000 |
2965 |
2965 |
2422 |
1605 |
352 |
2284 |
1605 |
1054 |
|
6450 |
3037 |
3037 |
2482 |
1644 |
361 |
2340 |
1644 |
1080 |
|
6900 |
200 |
3100 |
2518 |
1681 |
369 |
2393 |
1681 |
1105 |
|
7350 |
3100 |
3100 |
2592 |
1688 |
370 |
2400 |
1688 |
1109 |
|
1800 |
2335 |
3235 |
2644 |
1752 |
385 |
2493 |
1752 |
1152 |
|
8300 |
3363 |
3363 |
2699 |
1788 |
393 |
2545 |
1788 |
1176 |
|
Nominal |
SIZE(mm) |
|||||||
|
H |
h |
hi |
L |
LI |
BI |
|||
|
Atype |
Btype |
Ctype |
||||||
|
8500 |
3355 |
3355 |
2742 |
1800 |
395 |
2565 |
1800 |
11184 |
|
9300 |
3430 |
3430 |
2804 |
11850 |
417 |
2632 |
1850 |
11226 |
|
9900 |
3502| |
3502 |
2863 |
1896 |
417 |
2699 |
1896 |
1248 |
|
10500 |
3571| |
3571 |
2920 |
1934 |
425 |
2752 |
1934 |
1273 |
|
11100 |
3638 |
3638 |
2975 |
1970 |
433 |
2803 |
1970 |
1297 |
|
11700 |
3702| |
3702 |
3028 |
2005 |
441 |
2853 |
2005 |
1320 |
|
12300 |
3764 |
3764 |
3079 |
2039 |
448 |
2901 |
2039 |
1342 |
|
12900 |
3824 |
3824 |
3128 |
2072 |
455 |
2947 |
2072 |
1363 |
|
13500 |
3882| |
3882| |
3176 |
2104 |
462 |
2992 |
2104 |
1384 |
|
14100 |
3939 |
3939 |
3222 |
2135 |
469 |
3036 |
2135 |
1404 |
|
14700 |
3994 |
3994 |
3267 |
2165 |
476 |
3078 |
2165 |
1424 |
|
15400 |
4056 |
3318 |
2199 |
2199 |
483 |
3126 |
2199 |
1446 |
|
16100 |
4117 |
4117 |
3368 |
2232 |
490 |
3173 |
2232 |
1468 |
|
16900 |
4184 |
4184 |
3423 |
2268 |
498 |
3225 |
2268 |
1492 |
|
17800 |
4252 |
4252 |
3479 |
2308 |
506 |
13281 |
2308 |
1518 |
|
18800 |
4330 |
4330 |
3543 |
2350 |
5161 |
3341 |
2350 |
1546 |
|
20000 |
4420 |
4420 |
3611 |
2399 |
526 |
3411 |
2399 |
1578 |
|
21500 |
4528 |
4528 |
3705 |
2458 |
539 |
3194 |
2458 |
1617 |
|
23000 |
4631 |
4631 |
3789 |
2514 |
551 |
35731 |
2514 |
1654 |
|
24500 |
4730 |
1730 |
3870 |
2568 |
563 |
3649 |
2568 |
1689 |
|
26000 |
4825 |
4825 |
3947 |
2619 |
574 |
3722 |
2619 |
1723 |
|
27500 |
4916 |
4916 |
4021 |
2668 |
585 |
13792 |
2668 |
1756 |
|
29000 |
5004 |
5004 |
4093 |
2716 |
595 |
38601 |
2716 |
1787 |
|
31000 |
5126 |
5126 |
4188 |
2774 |
609 |
3949 |
2774 |
1822 |
|
33000 |
5234 |
5234 |
4276 |
2833 |
622 |
4032 |
2833 |
1860 |
|
35500 |
5363 |
5363 |
4381 |
2903 |
637 |
4132 |
2903 |
1906 |
|
38500 |
5510 |
5510 |
4502 |
2982 |
655 |
4245 |
2982 |
1958 |
|
42000 |
5672| |
5672| |
4634 |
3070 |
674 |
4370 |
3070 |
2015 |
|
46000 |
5847 |
5847 |
47771 |
3165 |
695 |
45051 |
3165 |
2078 |
