Dan Fox Anchors Parameters
Dan Fox Anchors, also known as Danforth Anchor, are a special type of anchor that is widely used in Marine and Marine engineering.
Nominal weight |
SIZE(mm) |
|||||
A |
B |
C |
D |
E |
F |
|
60 |
186 |
408 |
755 |
535 |
985 |
240 |
75 |
200 |
450 |
830 |
590 |
1080 |
260 |
100 |
216 |
490 |
930 |
640 |
1180 |
290 |
120 |
220 |
505 |
970 |
670 |
1230 |
300 |
125 |
234 |
520 |
1000 |
690 |
1270 |
310 |
150 |
242 |
550 |
1060 |
732 |
1348 |
330 |
200 |
266 |
600 |
1150 |
810 |
1490 |
360 |
250 |
294 |
650 |
1240 |
870 |
1600 |
390 |
276 |
296 |
660 |
1250 |
885 |
1620 |
400 |
300 |
312 |
690 |
1320 |
925 |
1700 |
420 |
400 |
342 |
750 |
1460 |
1010 |
1810 |
460 |
500 |
368 |
800 |
1570 |
1100 |
2020 |
490 |
750 |
414 |
910 |
1800 |
1260 |
2300 |
560 |
1000 |
450 |
980 |
1980 |
1380 |
2540 |
620 |
1250 |
484 |
1070 |
2100 |
1490 |
2740 |
670 |
1500 |
512 |
1120 |
2220 |
1580 |
2850 |
700 |
2000 |
560 |
1130 |
2440 |
1730 |
2910 |
770 |
2500 |
605 |
1217 |
2628 |
1864 |
3070 |
830 |
3000 |
640 |
1290 |
2790 |
1980 |
3330 |
880 |
4000 |
700 |
1420 |
3070 |
2170 |
3590 |
970 |
5000 |
735 |
1482 |
3200 |
2270 |
3840 |
1020 |
6000 |
800 |
1620 |
3500 |
2480 |
4100 |
1100 |
7000 |
840 |
1696 |
3850 |
2590 |
4180 |
1150 |
8500 |
910 |
1936 |
3940 |
2600 |
4490 |
1240 |
10000 |
940 |
2000 |
4150 |
2900 |
4640 |
1280 |
13600 |
1046 |
2120 |
4590 |
3250 |
5378 |
1440 |
16000 |
1105 |
2240 |
4845 |
3435 |
5680 |
1520 |
18000 |
1150 |
2270 |
5000 |
3570 |
5680 |
1580 |
20000 |
1190 |
2350 |
5175 |
3695 |
5880 |
1635 |
25000 |
1280 |
2530 |
5570 |
3982 |
6330 |
1760 |
Besqo Marine offers a wide range of Deck Machinery. For more information, leave message or send an email to sales@besqo.com.
