Ac-14 Anchor With Large Grip Parameters
Ac-14, dz-14 anchor with large holding force is called the second generation of rodless anchor. Its anchor crown is very wide, anchor claw is thick and long, and has longitudinal edge. The anchor has great weight and grip. Good stability. Commonly used as the main anchor for large container ships, motor carriers and supertankers, it is commonly used in Europe, America and Japan.
Ac-14 Has passed China CCS, China bureau of shipping inspection ZC, France BV, Italy RINA, Britain LR, Germany GL, Norway DNV, Japan NK, Korea KR, ABS certification.
Material: ZG200-400
Specification: 75-30000 kg
Surface: black paint
Certificates: CCS, ZC, BV, ABS, NK, LR, GL, RINA, KR, DNV
|
Nominal weight |
stzel mm |
|||||||
|
A |
B |
C |
D |
E |
F |
G |
J |
|
|
75 |
550 |
326 |
350 |
606 |
188 |
185 |
115 |
24 |
|
100 |
607 |
380 |
385 |
704 |
207 |
200 |
130 |
28 |
|
120 |
635 |
380 |
402 |
704 |
217 |
215 |
145 |
32 |
|
180 |
742 |
442 |
470 |
822 |
254 |
252 |
160 |
36 |
|
225 |
828 |
495 |
525 |
915 |
283 |
277 |
175 |
40 |
|
250 |
828 |
495 |
525 |
915 |
283 |
280 |
175 |
40 |
|
300 |
882 |
525 |
559 |
975 |
301 |
298 |
192 |
45 |
|
340 |
918 |
548 |
582 |
1015 |
313 |
310 |
215 |
48 |
|
360 |
918 |
548 |
582 |
1015 |
313 |
313 |
215 |
48 |
|
430 |
990 |
590 |
628 |
1098 |
339 |
336 |
215 |
48 |
|
495 |
1025 |
610 |
650 |
1135 |
350 |
348 |
235 |
50 |
|
585 |
1102 |
658 |
699 |
1220 |
376 |
375 |
235 |
50 |
|
675 |
1152 |
690 |
731 |
1278 |
394 |
390 |
255 |
60 |
|
766 |
1205 |
718 |
764 |
1336 |
411 |
408 |
255 |
60 |
|
855 |
1250 |
745 |
793 |
1385 |
427 |
420 |
280 |
62 |
|
970 |
1300 |
775 |
826 |
1445 |
444 |
440 |
280 |
62 |
|
1080 |
1350 |
805 |
855 |
1495 |
461 |
455 |
280 |
62 |
|
1200 |
1400 |
835 |
887 |
1545 |
478 |
470 |
310 |
68 |
|
1305 |
1440 |
858 |
913 |
1595 |
492 |
485 |
310 |
68 |
|
1440 |
1486 |
885 |
943 |
1645 |
507 |
505 |
310 |
68 |
|
1575 |
1534 |
915 |
972 |
1695 |
523 |
518 |
340 |
74 |
|
1710 |
1575 |
940 |
998 |
1745 |
538 |
532 |
340 |
74 |
|
1845 |
1616 |
965 |
1025 |
1785 |
552 |
546 |
340 |
74 |
|
1980 |
1650 |
985 |
1048 |
1830 |
564 |
560 |
380 |
82 |
|
2100 |
1686 |
1005 |
1070 |
1865 |
575 |
570 |
380 |
82 |
|
2295 |
1738 |
1035 |
1102 |
1920 |
593 |
588 |
380 |
82 |
|
2475 |
1780 |
1062 |
1128 |
1970 |
607 |
602 |
385 |
82 |
|
2655 |
1820 |
1085 |
1155 |
2018 |
621 |
615 |
385 |
82 |
|
2835 |
1862 |
1109 |
1180 |
2057 |
635 |
625 |
410 |
90 |
|
3040 |
1896 |
1130 |
1204 |
2100 |
646 |
640 |
410 |
90 |
|
3550 |
2030 |
1198 |
1287 |
2225 |
693 |
680 |
415 |
100 |
|
3940 |
2080 |
1240 |
1318 |
2300 |
709 |
705 |
450 |
100 |
|
4500 |
2170 |
1295 |
1376 |
2405 |
741 |
735 |
450 |
100 |
|
4840 |
2225 |
1330 |
1410 |
2465 |
760 |
755 |
480 |
110 |
|
5175 |
2275 |
1358 |
1443 |
2520 |
777 |
770 |
480 |
110 |
|
5610 |
2339 |
1396 |
1483 |
2590 |
798 |
790 |
500 |
110 |
|
6000 |
2390 |
1426 |
1515 |
2646 |
816 |
810 |
500 |
110 |
|
6225 |
2420 |
1443 |
1534 |
2678 |
826 |
820 |
540 |
117 |
|
6525 |
2450 |
1462 |
1554 |
2712 |
836 |
830 |
540 |
117 |
|
6975 |
2507 |
1496 |
1589 |
2775 |
855 |
848 |
580 |
121 |
|
7350 |
2560 |
1526 |
1622 |
2832 |
873 |
866 |
580 |
121 |
|
7875 |
2610 |
1558 |
1655 |
2890 |
891 |
884 |
600 |
130 |
|
8325 |
2665 |
1590 |
1689 |
2950 |
909 |
902 |
600 |
130 |
|
8775 |
2707 |
1614 |
1715 |
2996 |
924 |
916 |
630 |
135 |
|
9300 |
2765 |
1652 |
1754 |
3064 |
945 |
936 |
640 |
140 |
|
9675 |
2805 |
1674 |
1778 |
3104 |
957 |
948 |
640 |
140 |
|
10125 |
2850 |
1700 |
1806 |
3152 |
972 |
960 |
640 |
140 |
|
10575 |
2880 |
1720 |
1827 |
3192 |
984 |
976 |
660 |
145 |
|
11025 |
2930 |
1750 |
1859 |
3247 |
1001 |
990 |
660 |
145 |
|
11700 |
2987 |
1782 |
1894 |
3308 |
1019 |
1010 |
700 |
155 |
|
12075 |
3010 |
1800 |
1906 |
3343 |
1027 |
1020 |
700 |
155 |
|
12675 |
3065 |
1812 |
1945 |
3364 |
1047 |
1028 |
700 |
155 |
|
13350 |
3132 |
1870 |
1986 |
3470 |
1069 |
1060 |
700 |
155 |
|
14100 |
3178 |
1896 |
2015 |
3520 |
1084 |
1076 |
730 |
160 |
|
14700 |
3228 |
1924 |
2045 |
3570 |
1099 |
1090 |
730 |
160 |
|
15400 |
3272 |
1954 |
2075 |
3626 |
1117 |
1108 |
770 |
170 |
|
16100 |
3320 |
1980 |
2110 |
3680 |
1132 |
1125 |
770 |
170 |
|
16900 |
3350 |
2000 |
2126 |
3720 |
1144 |
1144 |
770 |
170 |
|
17250 |
3380 |
2016 |
2142 |
3740 |
1151 |
1144 |
770 |
170 |
|
17800 |
3440 |
2050 |
2180 |
3806 |
1173 |
1162 |
800 |
180 |
|
18800 |
3500 |
2088 |
2220 |
2875 |
1193 |
1185 |
800 |
180 |
|
20000 |
3573 |
2132 |
2265 |
3956 |
1220 |
1210 |
820 |
185 |
|
25000 |
4100 |
2437 |
2600 |
4577 |
1399 |
1375 |
880 |
200 |
|
30000 |
4358 |
2888 |
2765 |
4663 |
1484 |
1380 |
940 |
210 |
Besqo Marine offers a wide range of Deck Machinery. For more information, leave message or send an email to sales@besqo.com.
