Structural features
Unique planetary wheel reducer gear design and processing technology, strength of more than 1.5 times times the conventional gear, with small size, large tensile force, at least more than 1.25 times times the ability to overload operation.
|
Performance parameter Table |
|
|
Calibration tension |
4 Tonnes（39kn,9000LBS) |
|
Motor discharge |
80ml/rev |
|
Flow |
15-60L/min |
|
Pressure |
14mpa |
|
Deceleration ratio |
23:1 |
|
Wire Rope size (diameter × length) |
Φ11mm x25m |
|
Drum size (diameter × length) |
Φ88mmxΦ192mmx200mm |
|
Mounting size and mounting screw size |
300mmx280mm 8-m12 |
|
Dimensions (length × width × height) |
516mm(524)x 316mm(376)x237mm |
|
Weight (Kg) |
48kg |
Besqo Marine offers a wide range of Deck Machinery. For more information, leave message or send an email to sales@besqo.com.
