800KN Electric Mooring Winch Parameters

800KN Electric mooring winch is mainly used for ships, yacht ocean platforms and other places berthing or mooring or cable.

The use of winch, reel, marine planetary reducer, marine with brake speed regulating motor, main electric control box, main controller for IP56 type and asbestos-free environmental protection brake belt, base and so on.

Mooring winch strand shaft and shaft centerline parallel to the deck, the whole set of equipment installed on the deck, operation and management is more convenient. But the equipment occupies a large deck area and is vulnerable to wind and wave erosion.

General merchant ships use electric or hydraulic mooring winches more.

Vertical Cable Winch:

The center line of the winch shaft of the vertical cable is perpendicular to the deck. Both the motor and the reducer were placed under the deck, and only the reel stretched out on the deck, guided by the vertical shaft. No winch occupies a large deck area and is prone to wind and wave erosion of the shortcomings, warships on the use of vertical cable winch, this product safety is the highest.

Technical parameters:
Cable load: 800kN
Wire Rope Diameter: 60mm
Number Quantity: 600m
System Cable Speed: 6m/min Motor power: 70/70/45KW

Besqo Marine offers a wide range of Deck Machinery. For more information, leave message or send an email to sales@besqo.com.
