Lyc-B Series High Precision Oil Filter Parameters

LYC-B series high-precision oil filter includes a special gear pump driven by motor, which has the characteristics of low noise, strong self-suction ability and smooth operation.

The high pressure pipeline is equipped with overflow protection device, which can effectively protect the safety of hydraulic system.

Thermal relay protection is used to prevent motor damage caused by motor overload.

The oil suction Nozzle Coarse filter protects the oil pump and extends the service life of the main filter.

The pump is equipped with a level two precision filter, so that the oil quickly achieve a high degree of cleanliness.
The fine filter can choose different precision according to the different needs of the user, and meet the required requirements.

The Oil filter housing adopts a fast opening structure, without the need for any tools, it can quickly and easily open the upper cover, replace the filter cartridge. The panel is fitted with a pressure gauge, which continuously indicates the operating condition of the system and the degree of contamination of the filter cartridge at work.

Model: LYC-B

Nominal pressure: 0.6Mpa

Filtration Media: Hydraulic Oil

Application area: Hydraulic lubrication System

Technical parameters:

Model	LYC-32B-*/**	LYC-50B-*/**	LYC-63B-*/**	LYC-100B-*/**
Rated Flow  L/min	32	50	63	100
Rated pressure Mpa	0.6
Original pressure loss Mpa	≤0.02
Coarse filtration accuracy μm	100
First-level filtration accuracy μm	10、20、40
Two-stage filtration accuracy μm	3、5、10
Motor power kw	0.75	1.1	1.1	2.2
Voltage V	AC 380V Three-phase
Weight kg	90	100	108	150
Dimensions mm	720X680X1020	720X680X1020	720X680X1020	740X740X1180

 NOTE:

Accuracy for level two precision filters, such as 003 for 3 microns

For the applicable media, omitted: General hydraulic oil
BH: water, ethylene glycol
V: phosphoric acid ester Hydraulic Fluid
Applicable media viscosity ≤160cSt
