What Is LYC-B Series High Precision Oil Filter?

LYC-B series high precision oil filter is a kind of high precision equipment for filtering hydraulic oil and purifying oil, which can keep the safe and effective operation of the hydraulic system.

LYC-B series high-precision oil filter can not only be used as a filter equipment for injecting new oil into the hydraulic system, but also as a special equipment for regularly filtering impurities in the hydraulic system.

LYC-B series high-precision oil filter is composed of gear pump, filter, safety valve, oil return valve, drain water nozzle, filter bed (including pressure gauge, filter plate, filter frame, filter paper, oil pan), front support, rear support, chassis, tie rod, coupling and motor and other components.

The filter plate and the filter frame are alternately composed of each independent filter chamber, and the filter paper is sandwiched between the filter plate and the filter frame. When the oil passes through the filter bed, impurities and residual water in the oil can be removed through the capillary action of the filter paper to achieve high cleanliness.

LYC-B series high-precision oil filter has many advantages, such as high-precision filtration, trolley design, easy to move and so on. This series of oil filter can also achieve different filtration effects by deploying different filter elements according to different filtration accuracy requirements. In addition, LYC-B series high-precision oil filter is also equipped with high pressure pipeline overflow protection device, thermal relay protection, oil suction port coarse filter and other safety protection measures, which can ensure the safe and stable operation of the hydraulic system.

Besqo Marine offers a wide range of Auxiliary Machinery. For more information, leave message or send an email to sales@besqo.com.
