Box explosion-proof oil filter LYC-32C Parameters

Box-type explosion-proof oil filter LYC-32C uses a refined housing to cover all components to protect the equipment from external pollution, especially in the use of high environmental requirements of the occasion.

Box-type explosion-proof oil filter LYC-32C includes a special gear pump driven by the motor, with low noise, strong self-suction ability, smooth operation and so on.

The high pressure pipeline is equipped with overflow protection device, which can effectively protect the safety of hydraulic system.

Thermal relay protection is used to prevent motor damage caused by motor overload.

The oil suction Nozzle Coarse filter protects the oil pump and extends the service life of the main filter.

The pump is equipped with a level two precision filter, so that the oil quickly achieve a high degree of cleanliness.

The fine filter can choose different precision according to the different needs of the user, and meet the required requirements.

The Oil filter housing adopts a fast opening structure, without the need for any tools, it can quickly and easily open the upper cover, replace the filter cartridge. The panel is fitted with a pressure gauge, which continuously indicates the operating condition of the system and the degree of contamination of the filter cartridge at work.

Technical parameters

1. Rated Flow: 32L/min
2. Rated Pressure: 0.6Mpa
3. Pressure loss: ≤0.02Mpa
4. Filtration Level: Level 2
5. Filtration Accuracy: 3um-10um
6. Usage Temperature: 5-80 ℃
7. Motion Viscosity: ≦160CST
8. Motor power: 1.5kw
9. Motor Voltage: 380V 10. Weight: 100Kg
