High Viscosity Oil Filter Truck Parameters

High Viscosity Oil Filter Truck uses a special pump with high viscosity oil, the conveying fluid is smooth, no pulsation, low noise, small vibration, has a strong self-priming ability.



A wide range of corrosive media can be filtered, using temperatures up to 200 ℃.

Especially suitable for high viscosity oil filling and filtration.

Pipeline is equipped with overflow protection device, which can effectively protect the safety of hydraulic system.

The filter vehicle is protected by a thermal relay to prevent motor damage caused by the overload of the motor.

The oil suction Nozzle Coarse filter protects the oil pump and extends the service life of the main filter. The fine filter can choose different precision according to the different needs of the user, and meet the required requirements.

• Rated Flow: 80L/min
• Coarse filtration Accuracy: 100um
• Precision Filtration Accuracy: 3, 5, 10, 20, 40um
• Using media: High viscosity oil
• Working pressure: 1.0Mpa
• Original pressure loss: ≤0.2Mpa
• Filter replacement pressure difference: 0.2Mpa
• Oil viscosity: 10~760CST
• Usage temperature: 5~80°C
• Power: 4kw
• Voltage V:AC 380V Three-phase
• Weight kg:400
• Dimensions: 1500X740X1020

Besqo Marine offers a wide range of Auxiliary Machinery. For more information, leave message or send an email to sales@besqo.com.
