LQG Series Marine Coolers Parameters
LQG Series Marine Coolers each cooler can bear the cooling load of the whole system, the pipe plate is fixed, a floating, detachable bundle and water chamber box cover, easy to clean, inspect and repair during operation.
Cooler material, according to the use of places, water system conditions can have a variety of options.
LQG series of oil, freshwater cooler is mainly used for marine diesel engine slippery or marine circulating fresh water cooling, structure for shell expansion horizontal, pipe plate using HSN62-1 or composite plate, heat exchanger using HAL77-2 or B10 and other seawater corrosion resistant materials.
|
LQG Type Cooler Size table (two streams): |
|||||||||||||||||||
|
Type |
Cooling area |
Takeover path |
A |
B |
C |
D |
E |
F |
G |
H |
I |
J |
K |
L |
M |
N |
O |
P |
|
|
Pipe side |
Shell side |
||||||||||||||||||
|
LQG1-200/2 |
1 |
40 |
32 |
1106 |
110 |
100 |
160 |
121 |
80 |
150 |
500 |
850 |
150 |
150 |
100 |
150 |
60 |
30 |
4-M16 |
|
LQG2-200/2 |
2 |
50 |
40 |
1106 |
110 |
100 |
160 |
121 |
75 |
150 |
500 |
850 |
150 |
150 |
100 |
150 |
60 |
30 |
4-M16 |
|
LQG3-200/2 |
3 |
50 |
40 |
1406 |
110 |
100 |
160 |
121 |
75 |
150 |
800 |
1150 |
150 |
150 |
100 |
150 |
60 |
30 |
4-M16 |
|
LQG5-350/2 |
5 |
65 |
50 |
1521 |
120 |
110 |
170 |
131 |
92.5 |
150 |
850 |
1245 |
175 |
180 |
150 |
200 |
60 |
30 |
4-M16 |
|
LQG8-350/2 |
8 |
65 |
50 |
1187 |
140 |
130 |
200 |
136 |
142.5 |
150 |
500 |
875 |
250 |
260 |
230 |
280 |
60 |
30 |
4-M16 |
|
LQG10-350/2 |
10 |
80 |
65 |
1406 |
140 |
130 |
200 |
136 |
135 |
150 |
650 |
1094 |
250 |
260 |
230 |
300 |
60 |
30 |
4-M16 |
|
LQG15-400/2 |
15 |
100 |
80 |
1553 |
210 |
140 |
220 |
167 |
150 |
200 |
750 |
1140 |
250 |
290 |
250 |
300 |
60 |
30 |
4-M20 |
|
LQG20-400/2 |
20 |
125 |
100 |
1933 |
210 |
140 |
220 |
167 |
137.5 |
200 |
1000 |
1520 |
280 |
290 |
250 |
300 |
60 |
30 |
4-M20 |
|
LQG25-400/2 |
25 |
125 |
100 |
2333 |
210 |
140 |
220 |
167 |
137.5 |
200 |
1200 |
1900 |
280 |
290 |
250 |
300 |
60 |
30 |
4-M20 |
|
LQG30-400/2 |
30 |
125 |
100 |
2693 |
210 |
140 |
220 |
167 |
137.5 |
200 |
1600 |
2280 |
280 |
290 |
250 |
300 |
60 |
30 |
4-M20 |
|
LQG35-450/2 |
35 |
125 |
100 |
2539 |
250 |
140 |
240 |
192 |
137.5 |
200 |
1400 |
2061 |
280 |
一 |
一 |
一 |
一 |
一 |
一 |
