The Tubular Cooler Parameters
The tubular cooler consists of two cold and three-way valve units of the same area, one working, one spare.
Each cooler can bear the cooling load of the whole system, the pipe plate is fixed, a floating, detachable bundle and water chamber box cover, easy to clean, inspect and repair during operation.
Cooler material, according to the use of places, water system conditions can have a variety of options.
|
Specification/m2 |
A |
B |
C |
D |
F |
G |
H |
I |
J |
K |
L |
M |
P |
O |
S |
Quality/kg |
|
0.5 |
464 |
212 |
134 |
140 |
178 |
160 |
100 |
80 |
28 |
80 |
130 |
3 |
ф12 |
100 |
G3/4 |
17 |
|
0.7 |
522 |
270 |
192 |
18 |
||||||||||||
|
1 |
696 |
444 |
366 |
22 |
||||||||||||
|
1.6 |
986 |
734 |
656 |
27 |
||||||||||||
|
1.3 |
550 |
278 |
191 |
150 |
193 |
190 |
120 |
95 |
30 |
100 |
157 |
3 |
ф12 |
130 |
G1 |
30 |
|
2 |
706 |
434 |
347 |
34 |
||||||||||||
|
2.5 |
862 |
590 |
500 |
40 |
||||||||||||
|
3.5 |
1096 |
824 |
737 |
48 |
||||||||||||
|
3 |
674 |
382 |
285 |
160 |
208 |
230 |
145 |
115 |
50 |
130 |
188 |
4 |
ф14 |
164 |
G11/4 |
52 |
|
4 |
830 |
538 |
441 |
61 |
||||||||||||
|
4.5 |
908 |
616 |
519 |
65 |
||||||||||||
|
5.5 |
1064 |
772 |
675 |
73 |
||||||||||||
|
5 |
742 |
430 |
328 |
170 |
220 |
260 |
170 |
135 |
62 |
150 |
217 |
ф14 |
194 |
G11/2 |
71 |
|
|
6 |
830 |
518 |
416 |
77 |
||||||||||||
|
7 |
918 |
606 |
504 |
83 |
||||||||||||
|
9 |
1180 |
868 |
766 |
102 |
||||||||||||
|
8 |
793 |
446 |
332 |
180 |
246 |
290 |
195 |
155 |
70 |
180 |
246 |
4 |
ф14 |
224 |
G2 |
95 |
|
10 |
969 |
622 |
508 |
111 |
||||||||||||
|
12 |
1145 |
798 |
684 |
127 |
||||||||||||
|
14 |
1321 |
974 |
860 |
143 |
Besqo Marine offers a wide range of Auxiliary Machinery. For more information, leave message or send an email to sales@besqo.com.
