The HC300 Marine gearbox has the functions of reducing speed, reversing, cis clutch and bearing propeller thrust.
The gearbox is a vertical heterocentricle transmission structure with small volume, large speed ratio and light weight.
HC300 Marine gearbox is suitable for small fishing boat, inland river, coastal traffic boat, all kinds of transport ships.
|
700-2500r/min |
|||
|
Reduction ratio |
1.5、1.87、2.04、2.23、2.54、3、3.53 |
Transmission capacity |
0.257kw/r/min |
|
4.1、4.47 |
0.2kw/r/min |
||
|
4.61 |
0.184kw/r/min |
||
|
4.94 |
0.147kw/r/min |
||
|
5.44 |
0.13kw/r/min |
||
|
Manipulating type |
Push and pull soft shaft, electric control, air control |
||
|
The rated thrust |
50KN |
||
|
Center distance |
264mm |
||
|
Length x width x height |
680×930×880mm |
||
|
net weight |
680kg |
||
|
Join the flywheel |
12V135、12V150、SAE18、16、14 |
||
|
Join the trim |
12V135、12V150、SAE0、1 |
||
Besqo Marine offers a wide range of Host Device. For more information, leave message or send an email to sales@besqo.com.
