Main Parameters of 7JS100 Series Transmission

7JS100 series transmission is a transmission series produced by China Weichai Power Co., LTD. This series of transmission is suitable for all kinds of road trucks, dump trucks, off-road vehicles, tractors, truck cranes, mining vehicles, heavy fire trucks and railway rail cars with input torque of 1000N·m.

The structural characteristics of 7JS100 series transmission are:

It adopts the combination design of main and auxiliary boxes, the main box is operated by hand, the auxiliary box is operated by gas, 7 forward gear and 1 reverse gear.

The main and auxiliary boxes are driven by double intermediate shafts, and the main shaft and spindle gear of the main box are floating.

Double H control, single, double lever control or left, right and two-way control.

It can be equipped with front full power force extractor, side force extractor, bottom force extractor and rear force extractor.

The axial size is short, the weight is light, the bearing capacity is large, the use is reliable, the maintenance is convenient.
