Detailed Parameters of Cross Spiral Bevel Gear Box
The cross spiral bevel gear box is a kind of gear box, which contains two bevel gears installed at staggered angles. This design can generate additional forces along the axis during the transmission of power, thereby increasing the load capacity of the gear. This type of gearbox is usually used in situations where large transmission torque is required, such as Marine propulsion systems.
Product features:
1. A transmission gearbox that USES bevel gears to realize the commutation function, with stable work and large transmission torque;
2. Suitable for side-by-side conveyors or synchronous lifting platforms;
Main parameters:
- Output speed: 0.1-1450 RPM
- Output torque: maximum 5000n.m
- Transmission power: 0.18-90kw
- Shaft configuration: single shaft in single shaft out, single shaft in double shaft out, double shaft in single shaft out, double shaft in double shaft out
|
Quick selection table |
|||||
|
TC series model |
Axle diameter (mm) |
Center height (mm) |
Configured power (kw) |
Speed ratio |
Allowable torque (Nm) |
|
TC2 |
15k6 |
52h13 |
0.06~2.2 |
1:1~1:2 |
30 |
|
TC4 |
19k6 |
76h13 |
0.12~5.5 |
1:1~1:2 |
50 |
|
TC6 |
25k6 |
92h13 |
0.12~15 |
1:1~1:5 |
120 |
|
TC7 |
32k6 |
100h13 |
0.18~22 |
1:1~1:5 |
210 |
|
TC8 |
40k6 |
115h13 |
0.25~45 |
1:1~1:5 |
300 |
|
TC10 |
45k6 |
140h13 |
0.55~75 |
1:1~1:5 |
520 |
|
TC12 |
50k6 |
175h13 |
0.75~90 |
1:1~1:5 |
700 |
|
TC16 |
60m6 |
200h13 |
1.1~110 |
1:1~1:5 |
2000 |
|
TC20 |
72m6 |
245h13 |
1.5~200 |
1:1~1:5 |
5000 |
Besqo Marine offers a wide range of Host Device. For more information, leave message or send an email to sales@besqo.com.
