Detailed Parameters of GWC Series Marine Gearbox
GWC series Marine gearboxes are medium speed Marine gearboxes with 2 stages of reduction, the input and output are located in the same center, the same direction of operation. The product has the characteristics of compact structure, small size and smooth operation.
GWC series Marine gear boxes are widely used in transport ships, engineering ships, fishing boats and other ships.
GWC series Marine gear box specific parameters are as follows:
|
Product model |
Input speed |
Deceleration ratio |
Delivery capabilities |
Rated thrust |
Net |
|
（r/min） |
（i） |
（kW/r·min-1） |
（kN） |
（kg） |
|
|
GWC28.30 |
400-900 |
2.0607 |
0.781 |
80 |
1230 |
|
400-1150 |
2.5053 |
0.642 |
|||
|
400-1350 |
3.08 |
0.522 |
|||
|
400-1600 |
3.5353 |
0.455 |
|||
|
400-1800 |
4.0526 |
0.397 |
|||
|
4.5351 |
0.346 |
||||
|
5.0918 |
0.316 |
||||
|
5.5861 |
0.286 |
||||
|
6.1368 |
0.257 |
||||
|
GWC30.32 |
400-900 |
2.0317 |
1.066 |
100 |
1460 |
|
400-1150 |
2.5517 |
0.846 |
|||
|
400-1350 |
3.037 |
0.713 |
|||
|
400-1600 |
3.52 |
0.618 |
|||
|
400-1800 |
4 |
0.537 |
|||
|
4.5455 |
0.47 |
||||
|
5.0476 |
0.426 |
||||
|
5.641 |
0.375 |
||||
|
6.054 |
0.346 |
||||
|
GWC32.35 |
400-900 |
2.0585 |
1.346 |
113 |
2250 |
|
400-1150 |
2.5415 |
1.088 |
|||
|
400-1350 |
3.0211 |
0.9176 |
|||
|
400-1600 |
3.5759 |
0.772 |
|||
|
400-1800 |
4.0526 |
0.684 |
|||
|
4.593 |
0.602 |
||||
|
5.0894 |
0.537 |
||||
|
5.5724 |
0.493 |
||||
|
6.0789 |
0.448 |
||||
|
GWC36.39 |
400-900 |
1.9737 |
1.838 |
140 |
3000 |
|
400-1150 |
2.4502 |
1.471 |
|||
|
400-1350 |
2.9791 |
1.221 |
|||
|
400-1600 |
3.4737 |
1.044 |
|||
|
400-1800 |
3.9474 |
0.919 |
|||
|
4.3958 |
0.816 |
||||
|
5.0065 |
0.735 |
||||
|
5.4656 |
0.669 |
||||
|
5.9744 |
0.61 |
||||
|
GWC39.41 |
400-800 |
1.975 |
2.397 |
175 |
3250 |
|
400-1000 |
2.469 |
1.868 |
|||
|
400-1200 |
3.052 |
1.551 |
|||
|
400-1400 |
3.48 |
1.338 |
|||
|
400-1600 |
4.051 |
1.169 |
|||
|
400-1600 |
4.484 |
1.037 |
|||
|
4.996 |
0.919 |
||||
|
5.506 |
0.831 |
||||
|
5.999 |
0.757 |
||||
|
GWC42.45 |
400-800 |
2 |
3.147 |
220 |
3980 |
|
400-1000 |
2.5454 |
2.471 |
|||
|
400-1200 |
3.0244 |
2.081 |
|||
|
400-1400 |
3.5789 |
1.757 |
|||
|
400-1600 |
4 |
1.573 |
|||
|
4.4706 |
1.397 |
||||
|
5 |
1.243 |
||||
|
5.6 |
1.103 |
||||
|
5.931 |
1.044 |
||||
|
GWC45.49 |
400-700 |
1.9737 |
4.102 |
270 |
5280 |
|
400-900 |
2.4671 |
3.272 |
|||
|
400-1050 |
2.8947 |
2.721 |
|||
|
400-1250 |
3.466 |
2.353 |
|||
|
400-1400 |
3.9474 |
2.051 |
|||
|
4.3741 |
1.823 |
||||
|
4.8496 |
1.647 |
||||
|
5.5024 |
1.485 |
||||
|
5.9847 |
1.331 |
||||
|
GWC49.54 |
400-600 |
1.9359 |
5.412 |
284 |
7900 |
|
400-750 |
2.4593 |
4.257 |
|||
|
400-900 |
2.9172 |
3.588 |
|||
|
400-1050 |
3.4457 |
3.037 |
|||
|
400-1200 |
3.9524 |
2.647 |
|||
|
4.5336 |
2.294 |
||||
|
4.9105 |
2.11 |
||||
|
5.4823 |
1.882 |
||||
|
5.9967 |
1.721 |
||||
|
GWC49.59 |
400-1050 |
4 |
2.962 |
284 |
8500 |
|
400-1200 |
4.4761 |
2.647 |
|||
|
400-1200 |
5.009 |
2.365 |
|||
|
400-1200 |
5.5091 |
2.15 |
|||
|
GWC52.59 |
400-600 |
1.9341 |
7.059 |
300 |
9800 |
|
400-750 |
2.4817 |
5.493 |
|||
|
400-900 |
2.9643 |
4.603 |
|||
|
400-1050 |
3.5251 |
3.868 |
|||
|
400-1200 |
3.9524 |
3.448 |
|||
|
4.4314 |
3.059 |
||||
|
4.9725 |
2.662 |
||||
|
400-1200 |
5.4017 |
2.493 |
|||
|
5.9286 |
2.265 |
||||
|
GWC52.59A |
400-600 |
1.9341 |
7.059 |
Right machine：400 |
|
|
400-750 |
2.4817 |
5.493 |
Left machine：320 |
||
|
400-900 |
2.9643 |
4.603 |
|||
|
400-1050 |
3.5251 |
3.868 |
|||
|
400-1200 |
3.9524 |
3.448 |
|||
|
4.4314 |
3.059 |
||||
|
4.9725 |
2.662 |
||||
|
5.4017 |
2.493 |
||||
|
5.9286 |
2.265 |
||||
|
GWC52.62 |
400-565 |
2.017 |
7.326 |
300 |
10700 |
|
400-690 |
2.462 |
6 |
|||
|
400-845 |
3.019 |
4.893 |
|||
|
400-960 |
3.449 |
4.284 |
|||
|
400-1135 |
4.06 |
3.64 |
|||
|
400-1200 |
4.524 |
3.266 |
|||
|
5.042 |
2.931 |
||||
|
5.455 |
2.709 |
||||
|
5.945 |
2.486 |
||||
|
GWC60.66 |
400-600 |
2.0123 |
9.25 |
450 |
15000 |
|
400-750 |
2.499 |
7.265 |
|||
|
400-900 |
3.0722 |
6.169 |
|||
|
400-1050 |
3.5738 |
5.287 |
|||
|
400-1200 |
4.0513 |
4.625 |
|||
|
4.4838 |
4.022 |
||||
|
5.0786 |
3.662 |
||||
|
5.5061 |
3.331 |
||||
|
6.1161 |
3.029 |
||||
|
GWC60.66A |
400-600 |
2.0123 |
9.25 |
Right machine：550 |
|
|
400-750 |
2.499 |
7.265 |
Left machine：450 |
||
|
400-900 |
3.0722 |
6.169 |
|||
|
400-1050 |
3.5738 |
5.287 |
|||
|
400-1200 |
4.0513 |
4.625 |
|||
|
4.4838 |
4.022 |
||||
|
5.0786 |
3.662 |
||||
|
5.5061 |
3.331 |
||||
|
6.1161 |
3.029 |
||||
|
GWC60.74 |
400-530 |
1.9918 |
10.449 |
550 |
18000 |
|
400-670 |
2.5263 |
8.2383 |
|||
|
400-815 |
3.0566 |
6.809 |
|||
|
400-935 |
3.51 |
5.9259 |
|||
|
400-1070 |
4.0213 |
5.1756 |
|||
|
400-1200 |
4.5 |
4.625 |
|||
|
5.0357 |
4.133 |
||||
|
5.5125 |
3.7755 |
||||
|
6.0395 |
3.4461 |
||||
|
6.5 |
3.2019 |
||||
|
6.9429 |
2.9977 |
||||
|
GWC66.75 |
300-460 |
2.052 |
13.462 |
700 |
22000 |
|
300-580 |
2.553 |
10.823 |
|||
|
300-680 |
2.986 |
9.251 |
|||
|
300-795 |
3.482 |
7.934 |
|||
|
300-900 |
3.952 |
6.99 |
|||
|
4.486 |
6.158 |
||||
|
4.969 |
5.56 |
||||
|
300-900 |
5.509 |
5.014 |
|||
|
6.12 |
4.514 |
||||
|
GWC70.76 |
300-425 |
2.0481 |
15.643 |
750 |
25000 |
|
300-550 |
2.528 |
12.673 |
|||
|
300-700 |
3.0913 |
10.364 |
|||
|
300-810 |
3.5826 |
8.943 |
|||
|
300-900 |
3.95 |
8.111 |
|||
|
300-950 |
4.5737 |
7.005 |
|||
|
300-970 |
5.0472 |
6.348 |
|||
|
300-1000 |
5.5765 |
5.745 |
|||
|
6.1719 |
5.191 |
||||
|
GWC70.85 |
300-400 |
1.9762 |
19.2 |
800 |
30000 |
|
300-480 |
2.4505 |
15.484 |
|||
|
300-600 |
3.0072 |
12.617 |
|||
|
300-700 |
3.4928 |
10.863 |
|||
|
300-800 |
3.9524 |
9.6 |
|||
|
300-850 |
4.4724 |
8.484 |
|||
|
300-850 |
5.0503 |
7.513 |
|||
|
300-900 |
5.5798 |
6.8 |
|||
|
6.0521 |
6.269 |
||||
|
GWC75.90 |
200-465 |
2.0113 |
22.423 |
980 |
34000 |
|
200-580 |
2.5102 |
17.967 |
|||
|
200-695 |
3.0067 |
15 |
|||
|
200-815 |
3.5143 |
12.833 |
|||
|
200-925 |
3.9975 |
11.282 |
|||
|
200-1025 |
4.4324 |
10.175 |
|||
|
200-1100 |
5.0371 |
8.953 |
|||
|
5.4667 |
8.25 |
||||
|
6.0219 |
7.489 |
||||
|
GWC78.88 |
200-310 |
2.0387 |
23.372 |
1000 |
35000 |
|
200-390 |
2.495 |
19.101 |
|||
|
200-470 |
2.981 |
15.984 |
|||
|
200-570 |
3.476 |
13.709 |
|||
|
200-650 |
3.95 |
12.063 |
|||
|
200-680 |
4.489 |
10.616 |
|||
|
200-720 |
5.01 |
9.512 |
|||
|
200-750 |
5.469 |
8.713 |
|||
|
200-800 |
6.085 |
7.831 |
|||
|
GWC80.95 |
200-350 |
1.975 |
28 |
1200 |
40000 |
|
200-440 |
2.49 |
22.2 |
|||
|
200-520 |
2.94 |
18.81 |
|||
|
200-610 |
3.456 |
16 |
|||
|
200-700 |
3.95 |
14 |
|||
|
200-800 |
4.514 |
12.25 |
|||
|
5.027 |
11 |
||||
|
5.479 |
10.09 |
||||
|
5.925 |
9.33 |
||||
|
GWC85.100 |
150-270 |
1.975 |
35.4286 |
1400 |
46000 |
|
200-340 |
2.551 |
27.4286 |
|||
|
200-410 |
2.9844 |
23.4454 |
|||
|
200-480 |
3.4798 |
20.1081 |
|||
|
200-560 |
3.95 |
17.7143 |
|||
|
200-635 |
4.4838 |
15.6054 |
|||
|
200-700 |
4.9657 |
14.0909 |
|||
|
200-780 |
5.5061 |
12.7081 |
|||
|
200-845 |
5.9887 |
11.6839 |
|||
|
200-910 |
6.4517 |
10.845 |
|||
|
200-1000 |
7.0536 |
9.9198 Bottom of the formTop of the form Bottom of the form |
