Two-stage screw air compressor is a kind of high efficiency and energy saving air power equipment. Two-stage screw air compressor adopts two-stage compression technology to compress the gas twice, reducing the single-stage compression ratio, thereby reducing internal leakage and bearing load, and improving the compression efficiency and service life.
The two-stage screw air compressor is compact in structure, small in size, light in weight and easy to move and install.
The two-stage screw air compressor adopts the principle of screw compression, which has the characteristics of high efficiency and stability, and can provide continuous and stable compressed air.
The two-stage screw air compressor has the characteristics of energy saving and environmental protection, which can reduce energy consumption and reduce the impact on the environment.
The two-stage screw air compressor is equipped with an intelligent control system, which can realize remote control and monitoring, and facilitate users to grasp the operating status of the equipment in real time.
Two-stage screw air compressors are widely used in various industrial fields requiring compressed air, such as manufacturing, chemical industry, medicine and so on. It provides stable, efficient compressed air to meet the needs of a wide range of industrial applications. At the same time, due to its energy-saving and environmental protection characteristics, it can help enterprises reduce energy costs and meet environmental protection requirements.
|
Technical parameters: |
||||||
|
Model NO. |
Exhaust pressure |
Exhaust capacity |
Motor Power KW |
Outlet pipe diameter |
Weight kg |
Dimensions mm |
|
WBS-45A/WⅡ |
0.7～1.2 |
10.3～8.1 |
45 |
DN65 |
2100 |
2050×1200×1700 |
|
WBV-45A/WⅡ |
||||||
|
WBS-55A/WⅡ |
0.7～1.2 |
13.0～10.2 |
55 |
2200 |
||
|
WBV-55A/WⅡ |
||||||
|
WBS-75A/WⅡ |
0.7～1.2 |
16.2～13.4 |
75 |
2300 |
||
|
WBV-75A/WⅡ |
||||||
|
WBS-90A/WⅡ |
0.7～1.2 |
20.5～15.1 |
90 |
DN80 |
3500 |
2800×1600×1800 |
|
WBV-90A/WⅡ |
||||||
|
WBS-110A/WⅡ |
0.7～1.2 |
24.5～16.0 |
110 |
4000 |
||
|
WBV-110A/WⅡ |
||||||
|
WBS-132A/WⅡ |
0.7～1.2 |
30.0～19.5 |
132 |
4200 |
||
|
WBV-132A/WⅡ |
||||||
|
WBS-160A/WⅡ |
0.7～1.2 |
34.6～23.0 |
160 |
DN100 |
4500 |
3000×1900×1950 |
|
WBV-160A/WⅡ |
||||||
|
WBS-185A/WⅡ |
0.7～1.2 |
40.0～27.5 |
185 |
4700 |
||
|
WBV-185A/WⅡ |
||||||
|
WBS-200A/WⅡ |
0.7～1.2 |
42.5～32.0 |
200 |
DN100 |
7000 |
3600×2150×2150 |
|
WBV-200A/WⅡ |
||||||
|
WBS-220A/WⅡ |
0.7～1.2 |
51.5～38.0 |
220 |
8000 |
||
|
WBV-220A/WⅡ |
||||||
|
WBS-250A/WⅡ |
0.7～1.2 |
54.0～40.0 |
250 |
DN125 |
8200 |
|
|
WBV-250A/WⅡ |
||||||
